Description
The MaXtable HB-96D-Set (Model DH.WHB00199) is a premium dual-block dry heating incubator developed by DAIHAN Scientific (Korea). Compared with the basic “main unit only” configuration, the Set version is supplied with two standard 48-position aluminum blocks designed for 1.5/2.0 mL tubes, enabling immediate operation without additional accessories. Featuring a spacious dual-chamber architecture, the system effectively doubles sample processing capacity and is optimized for high-throughput laboratory workflows. It is ideally suited for enzyme reactions, DNA denaturation, cell culture applications, and various molecular biology and biochemical extraction procedures in research and diagnostic laboratories.
Product code: DH.WHB00199
CAS NO:
Brand: DAIHAN
Origin: HÀN QUỐC
Overview & Features
The system is equipped with dual independent digital controllers combined with a proprietary Jog-Shuttle push-and-turn knob, enabling rapid and precise setting of time and temperature parameters.
It features two high-efficiency molded heating units that tightly surround the aluminum block surfaces, ensuring fast heating rates and excellent temperature uniformity.
An intelligent automatic self-compensation function allows users to calibrate and correct deviations between the actual block temperature and the value displayed on the LCD screen.
The unit is constructed from high-quality materials, including a SUS304 stainless steel inner chamber, a heat-resistant powder-coated steel outer housing, and anodized aluminum heating blocks.
The complete package includes a transparent acrylic lid for optimal heat retention and reduced energy loss, as well as a stainless steel block handling tool for safe and convenient operation.
A multi-layer safety system provides laboratory protection through automatic shutdown in cases of over-temperature, over-current, or sensor failure detection.
Specifications
Model DH.WHB00199 configuration includes MaXtable HB-96D main unit, two standard 48-well aluminum blocks for 1.5/2.0 mL microcentrifuge tubes, a protective lid, and a block handling tool.
Block capacity: 2 independent aluminum blocks, each with dimensions W 90 × D 120 × H 60 mm.
Operating temperature range: Ambient +5°C to 150°C.
Temperature accuracy:
±0.1°C at 37°C
±0.2°C at 90°C
±0.4°C at 135°C
Temperature uniformity:
±0.2°C at 37°C
±0.4°C at 90°C
±0.8°C at 135°C
Heating system / total power: Two molded heating units with a combined output of 600 W.
Heating rate: Approx. 5°C per minute.
Temperature sensor: PT100.
Built-in timer: Up to 99 hours 59 minutes, with audible alarm for cycle completion or system error detection.
Display: Backlit digital LCD providing clear parameter visualization.
Main unit dimensions: W 285 × D 250 × H 155 mm.
Weight: 6 kg.
Power supply: Single phase, AC 230 V, 50/60 Hz.
