Safety Cabinets for Acid & Corrosives, "SCC-110", 2 Door, Manual, 2-Shelves, 1,100Lit

Safety Cabinets for Acid & Corrosives, "SCC-110", 2 Door, Manual, 2-Shelves, 1,100Lit

Description

The SciLab Acid and Corrosive Chemical Storage Cabinet, Model SCC-110 (Ordering No.: DH.SCC110 / Manufacturer Code: SL.SCCS110), is an extra-large capacity safety storage cabinet (1,100 L) developed by SciLab, South Korea. It is specifically designed for the centralized storage and safe containment of large volumes of highly corrosive chemicals, including strong acids and alkalis, thereby ensuring optimal operator safety, preventing the accumulation of hazardous vapors, and minimizing fire risks in large laboratories and industrial facilities.

Product code: DH.SCC110

CAS NO:

Brand: DAIHAN

Origin: HÀN QUỐC

Overview & Features

Specialized High-Performance Chemical-Resistant Coating: The entire cabinet surface is treated with a dedicated blue electrostatic powder coating. This high-durability finish provides excellent resistance to strong acids and alkalis, effectively protecting the steel structure from corrosion and rust caused by long-term accumulation of chemical vapors.

Protective Double-Wall Construction: The cabinet body is constructed with a robust double-wall design made of two 1.2 mm thick high-strength steel panels. A dedicated insulating air gap is incorporated between the panels, ensuring maximum protection for stored chemicals and effectively isolating external heat sources in the event of a fire.

Dual Manual Door Design: The cabinet is equipped with a two-door manual-opening system (non-self-closing), combined with integrated locking handles for secure operation. This configuration provides a wide access opening, allowing technicians to safely load and arrange large, heavy chemical containers such as drums, jerry cans, or cylinders.

Heavy-Duty Adjustable Shelving System: The cabinet is supplied with two heavy-duty galvanized steel shelves designed for high load capacity. The vertical support slot system inside the cabinet allows users to freely adjust shelf height and spacing to accommodate containers of various sizes and heights.

Ventilation and Air Circulation System: The cabinet is equipped with two Ø60 mm ventilation ports located symmetrically at the top and bottom, fitted with flame-arresting mesh screens for enhanced safety. This system enables flexible connection to a centralized exhaust system or external portable chemical fume filtration units, ensuring effective removal of toxic vapors and maintaining clean air circulation.

Specifications

Model: SCC-110 (Large Double-Door Upright Cabinet)

Ordering No.: DH.SCC110 (Official Manufacturer Code: SL.SCCS110)

Manufacturer: SciLab

Country of Origin: South Korea

Storage Capacity: 1,100 L (suitable for large-scale storage of corrosive chemicals)

Cabinet Construction: Double-wall structure with two 1.2 mm thick steel panels, finished with a specialized blue electrostatic powder coating offering excellent heat resistance and chemical corrosion resistance

Door Configuration: Double manual-opening doors (Manual)

Number of Shelves Supplied: 2 heavy-duty galvanized steel shelves with adjustable height positioning

Ventilation System: Equipped with two Ø60 mm ventilation ports arranged symmetrically at the top and bottom, fitted with integrated flame-arresting mesh screens for enhanced safety

External Dimensions (W × D × H): 150 × 86 × 165 cm (1500 × 860 × 1650 mm)

Internal Dimensions (W × D × H): 142 × 78 × 150 cm (1420 × 780 × 1500 mm)
